Description
nora® Lunairmed is an ultra lightweight expanded EVA sheet designed for applications requiring maximum cushioning, very low weight, and high walking comfort. With a hardness of approximately 16 Shore A and a density of around 0.08 g/cm³, Lunairmed provides excellent resilience and shock absorption while remaining extremely soft and flexible. The material is ideal for inner shoe cushioning, foot beddings, and orthotic constructions where comfort and pressure relief are essential.
Thanks to its closed cell structure, Lunairmed is hygienic, washable, and resistant to moisture, making it suitable for long term clinical use and for patients with sensitive or high risk feet. The material is available in smooth and perforated versions, allowing optimal bonding and flexibility in multilayer orthotic designs.
Material specification
-
Hardness: approx. 16 Shore A
-
Density: approx. 0.08 g/cm³
-
Surface: smooth or perforated
-
Sheet format: approx. 1080 × 825 mm (42.5 inch × 32.4 inch)
-
Thermoforming temperature: 110°C to 130°C (230°F to 266°F)
-
Bonding: compatible with standard EVA adhesives
-
Structure: closed cell expanded EVA
Available versions
Smooth
-
07 beige — 2 mm, 3 mm, 4 mm, 5 mm, 6 mm, 8 mm, 10 mm, 12 mm, 24 mm
-
80 anthracite — 2 mm, 3 mm, 4 mm, 6 mm, 8 mm
-
27 light blue — 2 mm, 3 mm, 4 mm, 6 mm
Perforated
Intended applications
-
Cushioning sheets for inner shoes
-
Foot orthotics and foot beddings
-
Shock absorbing layers in insoles
-
Sandwich type insole constructions
-
Pressure relief for diabetic and rheumatic feet
-
Upper material for interim and therapy shoes
-
Bathing and rehabilitation footwear
-
Low stress shaping elements such as calf prostheses
-
Soft lining material in orthoses
Key properties
-
Very low density EVA
-
Extremely soft and flexible
-
High resilience and elastic recovery
-
Excellent walking comfort
-
Good shock absorption
-
Hygienic closed cell structure
-
Washable and durable
-
Suitable for sensitive and diabetic feet
-
Ideal for multilayer constructions
Processing notes
-
Use standard EVA bonding methods
-
Adapt contact pressure to the flexibility of the material
-
Avoid excessive horizontal deformation during forming
-
Thermoform at 110°C to 130°C (230°F to 266°F)
nora® Lunairmed is ideal for orthotic, prosthetic, and orthopaedic footwear workshops requiring a very soft, lightweight EVA material for cushioning, pressure relief, and high comfort applications, especially in diabetic care, rheumatic conditions, and sandwich type insole constructions.
